Salter-Harris fractures
Background
- The higher the classification, the higher the likelihood of growth abnormalities
- If physis fracture missed may lead to premature closure and bone growth arrest
- It was previously taught that ligaments are stronger than bones in kids (and fractures were more likely than sprains), however newer studies (to date in ankles) contradict that assumption[1]
Mnemonic
- S 1 - Slipped (through physis/growth plate)
- A 2 - Above (physis with metaphysis fracture)
- L 3 - Lower (physis with epiphysis fracture)
- T 4 - Through (physis, metaphysis and epiphysis fracture)
- R 5 - Rammed (growth plate crushed)
Fracture Chart
| Type | I (Slip) | II (Above) | III (Below) | IV (Through) | V (Crush) |
| Fracture Location | hypertrophic zone of physis (epiphysis separates from metaphysis) | Through physis and out through piece of metaphyseal bone | Intra-articular | Starts at articular surface and extends through epiphysis, physis, metaphysis | Physis compression |
| Pathophysiology | Growing cells remain on the epiphysis in continuity with blood supply | Growing cells remain on the epiphysis in continuity with blood supply | fracture extends from epiphysis through physis | ||
| Epidemiology | Occurs mostly in infants and todlers | Most common type of fracture | Typically occurs at knee or ankle | ||
| Prognosis | Good | Good | Moderate | Moderate | Highest chance of growth arrest |
Clinical Features
- Trauma with point tenderness over a non-closed (pediatric) physis
Differential Diagnosis
- Sprain
- Contusion
- Other fracture
Evaluation
Type 1 (Slip)
- Suspect if point tenderness over a physis
- X-ray findings are subtle (epiphyseal displacement) or absent (clinical diagnosis)
- Often radiograph negative
Type 2 (Above)
- X-ray shows triangular fragment of metaphysis with out injury to epiphysis
Type 3 (Below)
- X-ray shows epiphyseal fragment not associated with etaphyseal fracture
- Greater the displacement greater chance of vascular supply compromise
Type 4 (Both)
- fracture starts at articular surface and extends through epiphysis, physis, metaphysis
Type 5 (Crush)
- X-ray shows physis compression fracture
- May confuse for Type 1 injury: differentiation based on clinical presentation, history, and exam.
- X-ray findings may be minimal
Management
General Fracture Management
- Acute pain management
- Open fractures require immediate IV antibiotics and urgent surgical washout
- Neurovascular compromise from fracture requires emergent reduction and/or orthopedic intervention
- Consider risk for compartment syndrome
Type I
Radiograph-negative ankle injury (peds) Low risk mechanism
- Most: Removable brace [2][3][4][5]
- Return to activities as tolerated by pain
- Follow up with pediatrician
Type II
- Most: Splint, ortho follow up
- Ankle injury - Consider removable ankle brace[2]
Type III-V
- Splint, ortho consult
Disposition
- Outpatient
See Also
- Fractures
- Radiograph-negative ankle injury (peds)
- Triplane fracture (type IV fracture of distal tibia)
